Home Industrial Membrane Element

Ultra Low Pressure RO Membrane Element

Ultra Low Pressure RO Membrane ElementUltra Low Pressure RO Membrane ElementUltra Low Pressure RO Membrane Element

Product Introduction

High Flux, Low operating cost,30% below standard operating pressure, Long Life.

Product details

Usage

It is applicable to the desalination of municipal water, groundwater with salt concentration less than 1500ppm. It can be widely used in residential dual water supplying system, pure water preparation plant, industry, food production and other fields etc.

Specifications & Parameters
Model Active Membrane
Area ft2(m2)
Concentrate Channel
Spacer (mil)
Permeate Flow
GPD(m3/d)
Stable Rejection
Rate (%)
Minimum Rejection
Rate (%)
ULP-4040HF 100(9.3) 28 2700(10.2) 99.50 99.40
Standard Test Condition
Concentration of Solution (NaCl) Temperature(℃) pH Value Operating Pressure psi(MPa) Recovery Rate(%)
1500mg/L 25 7.5-8 150(1.03) 15

Notes: The permeate flow of single membrane element may vary with in ±15%.

Operating Limits and Conditions of Membrane Element:

Max.Working Pressure 600 psi(4.14MPa)
Max. FeedWater Temperature 45 ℃
Max. FeedWaterSDI15 5.0
Max. Feed Water Flow 3.6m3/h
Free Chlorine Concentration of FeedWater 0.1mg/L
pH Range of FeedWaterDuring Continuous Operation 3-10
pH Range of FeedWaterDuring Chemical Cleaning 1-13
Max. Pressure Drop of Single Membrane Element 15psi(0.1Mpa)
